Model-Based Cloud Resource Provisioning with TOSCA and OCCI

With the advent of cloud computing, different cloud providers with heterogeneous cloud services (compute, storage, network, applications, etc.) and their related Application Programming Interfaces (APIs) have emerged. This heterogeneity complicates the implementation of an interoperable cloud system. Several standards have been proposed to address this challenge and provide a unified interface to cloud resources. The Open Cloud Computing Interface (OCCI) thereby focuses on the standardization of a common API for Infrastructure-as-a-Service (IaaS) providers while the Topology and Orchestration Specification for Cloud Applications (TOSCA) focuses on the standardization of a template language to enable the proper definition of the topology of cloud applications and their orchestrations on top of a cloud system. TOSCA thereby does not define how the application topologies are created on the cloud. Therefore, we analyse the conceptual similarities between the two approaches and we study how we can integrate them to obtain a complete standard-based approach to manage both cloud infrastructure and cloud application layers. We propose an automated extensive mapping between the concepts of the two standards and we provide TOSCA Studio, a model-driven tool chain for TOSCA that conforms to OCCI. TOSCA Studio allows to graphically design cloud applications as well as to deploy and manage them at runtime using a fully model-driven cloud orchestrator based on the two standards. Our contribution is validated by successfully designing and deploying two cloud applications: WordPress and Node Cellar.
