LOCAT: Low-Overhead Online Configuration Auto-Tuning of Spark SQL Applications [Extended Version]

Spark SQL has been widely deployed in industry but it is challenging to tune its performance. Recent studies try to employ machine learning (ML) to solve this problem, but suffer from two drawbacks. First, it takes a long time (high overhead) to collect training samples. Second, the optimal configuration for one input data size of the same application might not be optimal for others. To address these issues, we propose a novel Bayesian Optimization (BO) based approach named LOCAT to automatically tune the configurations of Spark SQL applications online. LOCAT innovates three techniques. The first technique, named QCSA, eliminates the configuration-insensitive queries by Query Configuration Sensitivity Analysis (QCSA) when collecting training samples. The second technique, dubbed DAGP, is a Datasize-Aware Gaussian Process (DAGP) which models the performance of an application as a distribution of functions of configuration parameters as well as input data size. The third technique, called IICP, Identifies Important Configuration Parameters (IICP) with respect to performance and only tunes the important ones. As such, LOCAT can tune the configurations of a Spark SQL application with low overhead and adapt to different input data sizes. We employ Spark SQL applications from benchmark suites TPC-DS, TPC-H, and HiBench running on two significantly different clusters, a four-node ARM cluster and an eight-node x86 cluster, to evaluate LOCAT. The experimental results on the ARM cluster show that LOCAT accelerates the optimization procedures of the state-of-the-art approaches by at least 4.1x and up to 9.7x; moreover, LOCAT improves the application performance by at least 1.9x and up to 2.4x. On the x86 cluster, LOCAT shows similar results to those on the ARM cluster.
