中科院自动化所吴毅红研究员在第八届视觉与学习青年学者研讨会（VALSE）上做了三维计算视觉年度进展报告，详细介绍了图像匹配、视觉定位、三维重建等领域的研究进展。

2018年4月20日至22日，第八届视觉与学习青年学者研讨会(Vision And Learning SEminar, VALSE)于大连市成功举办。本届研讨会由大连理工大学承办，3000余名学者出席此次会议。

大会现场（图片来自网络）

会上，自动化所吴毅红研究员做了题为《2017以来的2D to 3D》的报告，详细介绍了图像匹配、视觉定位、三维重建等领域的研究进展。下面是报告的部分文字内容摘录(文末附PPT全文下载链接)。

图像匹配

概况

• 传统设计的描述子逐渐被学习型描述子取代，深度学习成为主流趋势

• 深度学习开始在特征检测领域展现光彩

• 实际使用中，仍然是传统设计方法为主

学习型特征检测算法

• CovDet:CNN学习协变(Covariant)特征,Zhang,Yu, Kumar, Chang, CVPR2017

• AffNet: CNN学习仿射协变参数, Mishkin, Radenovic, Matas, arXiv2017

学习型特征检测算法

• L2Net: 新的采样模式及误差, Tian, Fan, Wu, CVPR2017

• DeepCD: 浮点描述子与二值描述子互补, Yang, Hsu, Lin, Chuang, ICCV2017

• Spread-out: 学习描述子的空间分布, Zhang, Yu, Kumar, Chang, ICCV2017

• HardNet: 基于L2Net的改进误差, Mishchuk, Mishkin, Radenovic, Matas, NIPS2017

特征匹配方法

• J. Bian, W. Lin, Y. Matsushita, S. Yeung, T. Nguyen, M. Cheng. GMS: Grid-based Motion Statistics for Fast, Ultra-robust Feature Correspondence. CVPR2017(利用运动平滑信息进行特征匹配，快速、鲁棒)

• A. Seki, M. Pollefeys. SGM-Nets: Semi-global matching with neural networks. CVPR 2017. KITTI, Stereo 2012, rank 10

SGM: H. Hirschmuller. Stereo Processing by Semiglobal Matching and Mutual Information, PAMI 2008.

测评

• Johannes L. Schonberger, Hans Hardmeier, Torsten Sattler, Marc Pollefeys. Comparative Evaluation of Hand-Crafted and Learned Local Features. CVPR 2017.

新的数据库: Hpatches

描述子学习领域可用数据集较少，之前的Brown数据集性能趋于饱和。HPatches在数据质量上较Brown数据集进一步提升，评测方法更有效、多样。

• HPatches A benchmark and evaluation of handcrafted and learned local descriptor. V. Balntas, K. Lenc, A. Vedaldi, K. Mikolajczyk. In CVPR 2017

视觉定位

13D点已知:大场景，异质数据

• Nathan Piasco, Désiré Sidibé, Cédric Demonceaux, Valérie Gouet-Brunet. A survey on Visual-Based Localization: On the benefit of heterogeneous data. Pattern Recognition, 2018.

• Liu Liu, Hongdong Li, and Yuchao Dai. Efficient Global 2D-3D Matching for Camera Localization in a Large-Scale 3D Map, ICCV 2017.

• Dylan Campbell, Lars Petersson, Laurent Kneip and Hongdong Li. Globally-Optimal Inlier Set Maximisation for Simultaneous Camera Pose and Feature Correspondence, ICCV 2017.

• Youji Feng, Yihong Wu, and Lixin Fan. Real-time SLAM Relocalization with On-line Learning of Binary Feature Indexing. Machine Vision and Applications, 2017.

• Jian Wu, Liwei Ma and Xiaolin Hu. Delving Deeper into Convolutional Neural Networks for Camera Relocalization. ICRA 2017.

• T. Qin, P. Li and S. Shen. Relocalization, Global Optimization and Map Merging for Monocualr Visual-Inertial SLAM. ICRA 2018.

23D点未知: SLAM

综述

• C. Cadena, L. Carlone, H. Carrillo, Y. Latif, D. Scaramuzza, J. Neira, I. Reid, and J.J. Leonard. Past, Present, and Future of Simultaneous Localization and Mapping: Toward the Robust-Perception Age. IEEE TRANSACTIONS ON ROBOTICS, 32(6), 2016.

• G. Younes, D. Asmar, E. Shammas, J. Zelek. Keyframe-based monocular SLAM: design, survey, and future directions. Robotics and Autonomous Systems 98 (2017) 67–88

复杂环境下的鲁棒视觉定位

通过点/线/面等多种几何元素的融合，解决弱纹理、强光线、长通道等环境下的视觉定位问题；通过多目/多传感器融合，提升复杂环境下的视觉定位精度和鲁棒性。

• A. Pumarola, A. Vakhitov, et al. PL-SLAM: Real-Time Monocular Visual SLAM with Points and Lines. ICRA 2017.(点线)

• S. C. Yang and S. Scherer. Direct Monocular Odometry Using Points and Lines. ICRA 2017. (点线)

• S. C. Yang, Y. Song, et al. Pop-up SLAM: Semantic Monocular Plane SLAM for Low-texture Environments. IROS 2016.(平面)

• P. F. Proenca and Y. Gao. Probabilistic rgb-d odometry based on points lines and planes under depth uncertainty.arXiv.org, 2017.(线面)

• K. Sun, K. Mohta, et al. Robust Stereo Visual Inertial Odometry for Fast Autonomous Flight. IEEE Robotics and Automation Letters, 2018. (双目+IMU)

• R. Wang, M. Schworer and D. Cremers. Stereo DSO: Large-Scale Direct Sparse Visual Odometry with Stereo Cameras. ICCV 2017. (双目)

• K. Qiu, T. Liu and S. Shen. Model-based global localization for aerial robots using edge alignment. IEEE Robotics and Automation Letters, 2(3):1256-1263, 2017. (边缘)

• Y. Ling, M. Kuse and S. Shen. Edge alignment-based visual-inertial fusion for tracking of aggressive motions. Autonomous Robots, pages 1-16, 2017. (边缘)

• Y. Ling and S. Shen. Building maps for autonomous navigation using sparse visual SLAM features. IROS 2017.

学习或与几何融合的视觉定位

通过学习或与几何融合的方法提升视觉定位鲁棒性或精度：利用深度学习来估计深度和相机姿态，弥补几何方法在弱纹理区域的不足；同时，利用几何方法进一步提升深度和相机姿态的精度。

• K. Tateno, F. Tombari, et al. CNN-SLAM: Real-time Dense Monocular SLAM with Learned Depth Prediction. CVPR 2017.

• B. Ummenhofer, H. Z. Zhou, et al. DeMoN: Depth and Motion Network for Learning Monocular Stereo. CVPR 2017.

• T. H. Zhou, M. Brown, N. Snavely, D.G. Lowe. Unsupervised Learning of Depth and Ego-Motion from video. CVPR 2017.

• S. Vijayanarasimhan, S. Ricco, et al. Sfm-Net: Learning of Structure and Motion from Video. arXiv:1704.07804, 2017.

• R. Li, S. Wang, et al. UnDeepVO: Monocular Visual Odometry through Unsupervised Deep Learning. arXiv: 1709.06841, 2017.

• D. Detone, T. Malisiewicz, A. Rabinovich. Toward Geometric Deep SLAM. arXiv:1707.07410, 2017.

• R. Clark, S. Wang, et al. VINet: Visual-Inertial Odometry as a Sequence-to-Sequence Learning Problem. AAAI 2017.

• Xiang Gao, Tao Zhang. Unsupervised learning to detect loops using deep neural networks for visual SLAM system. Auton Robot (2017) 41:1–18.

• Helder J. Araujo et al. Deep EndoVO: A Recurrent Convolutional Neural Network (RCNN) based Visual Odometry Approach for Endoscopic Capsule Robots, Neurocomputing, 2017.

语义SLAM

从几何和内容两个层次感知世界，对地图内容进行抽象理解。通过语义理解，辅助SLAM提高建图和定位的精度；通过SLAM，帮助扩展语义理解的场景。

• S. L. Bowman, N. Atanasov, et al. Probabilistic Data Association for Semantic SLAM. ICRA 2017. (Best Paper,5篇最佳论文之一)

• J. McCormac, A. Handa, et al. Semantic Fusion: Dense 3D Semantic Mapping with Convolutional Neural Networks. ICRA 2017.

基于Marker的SLAM

• Joseph DeGol, Timothy Bretl and Derek Hoiem. ChromaTag : A Colored Marker and Fast Detection Algorithm. ICCV, 2017.

• R. Munoz-Salinas, M.J. Marin-Jimenez, E. Yeguas-Bolivar, R. Medina-Carnicer. Mapping and localization from planar markers. Pattern Recognition, Vol. 73, pp. 158-171, 2018.

• Y. Wu. 轻量级无痕 marker SLAM. Patent, 2017. (不需要匹配，不需要PnP)

Event Camera SLAM, RGBD SLAM

基于事件相机的SLAM：事件相机的每个像素都在独立异步地感知接收光强变化，利用这种相机的低功耗、低带宽和对亮度变化非常敏感的性质来构建视觉SLAM系统。

• G. Gallego, Jon E. A. Lund, et al. Event-based, 6-DOF Camera Tracking from Photometric Depth Maps. PAMI, 2017.

• T. Rosinol Vidal, H. Rebecq, et al. Ultimate SLAM? Combining Events,Images, and IMU for Robust Visual SLAM in HDR and High Speed Scenarios.IEEE Robotics and Automation Letters, 2018

• H. Rebecq, T. Horstschaefer and D. Scaramuzza. Real-time Visual-Inertial Odometry for Event Cameras using Keyframe-based Nonlinear Optimization. BMVC 2017.

深度学习方法呈上升趋势

传统几何方法热情不减

实际应用还是传统的多视几何方法为主导

三维重建

1从运动恢复结构(SFM)

增量式进展

• Hainan Cui, Shuhan Shen, Xiang Gao, Zhanyi Hu. Batched Incremental Structure-from-Motion. 3DV 2017

• Jianwei Li, Wei Gao, Yihong Wu. Elaborate Scene Reconstruction with a Consumer Depth Camera. International Journal of Automation and Computing，2017.

全局式进展

• Hainan Cui, Shuhan Shen, Zhanyi Hu. Global Fusion of Generalized Camera Model for Efficient Large-Scale Structure from Motion. Science China: Information Sciences, 60: 038101:1–038101:3, 2017.

混合式进展

第一种：将摄像机位置和姿态求取拆开

Hainan Cui, Xiang Gao, Shuhan Shen, Zhanyi Hu. HSfM: Hybrid Structure-from-Motion. CVPR 2017.

第二种：将摄像机进行分组，每一组进行增量式重建，组之间再进行模型对齐时采用全局式方法。

• Hainan Cui, Shuhan Shen, Xiang Gao, Zhanyi Hu. CSfM: Community-based Structure from Motion， ICIP 2017.

• Siyu Zhu, Tianwei Shen, Lei Zhou, Runze Zhang, Jinglu Wang, Tian Fang, Long Quan. Parallel Structure from Motion from Local Increment to Global Averaging. ICCV 2017.

捆绑调整

• Runze Zhang, Siyu Zhu, Tian Fang, Long Quan. Distributed Very Large Scale Bundle Adjustment by Global Camera Consensus. 29-38, ICCV 2017.

• Hainan Cui, Shuhan Shen, Zhanyi Hu. Tracks Selection for Robust, Efficient and Scalable Large-Scale Structure from Motion. PR 2017.

天地融合

• Lei Zhou, Siyu Zhu, Tianwei Shen, Jinglu Wang, Tian Fang, Long Quan. Progressive Large Scale-Invariant Image Matching in Scale Space. ICCV 2017.

• Xiang Gao, Lihua Hu, Hainan Cui, Shuhan Shen, Zhanyi Hu. Accurate and Efficient Ground-to-Aerial Model Alignment. Pattern Recognition, 76(4): 288-302, 2018.

• Yang Zhou, Shuhan Shen, Xiang Gao, Zhanyi Hu. Accurate Mesh-based Alignment for Ground and Aerial Multi-view Stereo Models. ICIP 2017.

点云处理

• Nan. et al., PolyFit: Polygonal Surface Reconstruction from Point Clouds, ICCV 2017

• Kelly. et al., BigSUR: Large-scale Structured Urban Reconstruction, TOG 2017

• Zhu. et al., Variational Building Modeling from Urban MVS Meshes, 3DV 2017

2学习深度

• Clement Godard, Oisin Mac Aodha, Gabriel J. Brostow. Unsupervised Monocular Depth Estimation With Left-Right Consistency. CVPR 2017. (左右视图视差的一致性)

• T. H. Zhou, M. Brown, N. Snavely, D.G. Lowe. Unsupervised Learning of Depth and Ego-Motion from video. CVPR 2017. (同时估计当前帧的深度以及相邻帧的相机相对姿态)

• Lei He, Guanghui Wang and Zhanyi Hu. Learning Depth from Single Images with Deep Neural Network Embedding Focal Length, IEEE Transactions on Image Processing, 2018.

将固定焦距数据集转换成了多焦距数据集；将焦距信息以全连接层的形式嵌入到全局特征网络中。

非刚体

• Suryansh Kumar, Yuchao Dai, Hongdong Li. The 1st Winner of “Non-Rigid Structure from Motion Challenge 2017” @ CVPR 2017

• Suryansh Kumar, Yuchao Dai, Hongdong Li. Spatial-temporal union of subspaces for multi-body non-rigid structure-from-motion. Pattern Recognition, 2017. (An unified framework to jointly segment and reconstruct multiple non-rigid objects, along both temporal direction and spatial direction)

• Suryansh, Yuchao Dai, Hongdong Li. Monocular Dense 3D Reconstruction of a Complex Dynamic Scene from Two Perspective Frames, ICCV 2017.

• Kangkan Wang, Guofeng Zhang, Shihong Xia. Templateless Non-Rigid Reconstruction and Motion Tracking With a Single RGB-D Camera. IEEE Transactions on Image Processing, 26(12): 5966 – 5979, 2017.

其余

• T. Schoeps, T. Sattler, C. Haene, M. Pollefeys. Large-scale outdoor 3D reconstruction on a mobile device. CVIU 2017. (filter based method)

• C. Haene, C. Zach, A. Cohen, M. Pollefeys, Dense Semantic 3D Reconstruction, PAMI, 2017.(volumetric)

• Zhaopeng Cui, Jinwei Gu, Boxin Shi, Ping Tan and Jan Kautz. Polarimetric Multi-View Stereo. CVPR 2017.(从偏振，光度，法向信息，无纹理进行重建)

发展趋势

几何与学习融合

目前深度学习已广泛应用于计算机视觉领域，但在三维计算机视觉方面，深度学习方法的性能还超越不了传统的几何方法。传统方法有退化和不鲁棒的时候，如纯旋转进行三维重建，可用深度学习方法来弥补。深度学习方法泛化能力弱，很多情况下直接学习结构和运动精度较低，但有强大的特征表达能力。因此，以传统多视几何主导三维视觉，辅以深度学习，是提高三维视觉鲁棒性的一种发展趋势。

多传感器融合

当视觉环境复杂多变、即使深度学习也不能弥补时，辅以其余的传感器是一种有效方式。相比其余传感器，视觉传感器灵活、普遍、成本低廉。在要求低成本时，以视觉传感器主导，辅以廉价的激光、IMU等，可达到性能和成本兼顾的目的。

与硬件结合

目前已有很多深度相机、3D摄像头，但有些接口使用起来并不方便；将三维视觉的算法与硬件结合，嵌入到硬件或芯片中，是一种发展趋势。

M. Abouzahir, A. Elouardi, R. Latif, S. Bouaziz, A. Tajer. Embedding SLAM algorithms: Has it come of age? Robotics and Autonomous Systems 100 (2018) 14–26.

该文将几种典型的SLAM算法嵌入到芯片中，并对性能进行了分析和比较。

与具体应用结合

三维视觉在AGV、无人驾驶、服务机器人、AR教育、AR影音等方面有广泛的应用价值。
