笔记本电池是针对 Windows 操作系统进行了高度优化的，当我在笔记本电脑中使用 Windows 操作系统时，我已经意识到这一点，但对于 Linux 来说却不一样。
多年来，Linux 在电池优化方面取得了很大进步，但我们仍然需要做一些必要的事情来改善 Linux 中笔记本电脑的电池寿命。
当我考虑延长电池寿命时，我没有多少选择，但我觉得 TLP 对我来说是一个更好的解决方案，所以我会继续使用它。
在本教程中，我们将详细讨论 TLP 以延长电池寿命。
我们之前在我们的网站上写过三篇关于 Linux 笔记本电池节电工具 的文章：PowerTOP 和 电池充电状态。
TLP
TLP 是一款自由开源的高级电源管理工具，可在不进行任何配置更改的情况下延长电池寿命。
由于它的默认配置已针对电池寿命进行了优化，因此你可能只需要安装，然后就忘记它吧。
此外，它可以高度定制化，以满足你的特定要求。TLP 是一个具有自动后台任务的纯命令行工具。它不包含GUI。
TLP 适用于各种品牌的笔记本电脑。设置电池充电阈值仅适用于 IBM/Lenovo ThinkPad。
所有 TLP 设置都存储在 /etc/default/tlp 中。其默认配置提供了开箱即用的优化的节能设置。
以下 TLP 设置可用于自定义，如果需要，你可以相应地进行必要的更改。
TLP 功能
x86_energy_perf_policy）
如何在 Linux 上安装 TLP
TLP 包在大多数发行版官方存储库中都可用，因此，使用发行版的 包管理器 来安装它。
对于 Fedora 系统，使用 DNF 命令 安装 TLP。
-
$ sudo dnf install tlp tlp-rdw
ThinkPad 需要一些附加软件包。
-
$ sudo dnf install https://download1.rpmfusion.org/free/fedora/rpmfusion-free-release-$(rpm -E %fedora).noarch.rpm
-
$ sudo dnf install http://repo.linrunner.de/fedora/tlp/repos/releases/tlp-release.fc$(rpm -E %fedora).noarch.rpm
-
$ sudo dnf install akmod-tp_smapi akmod-acpi_call kernel-devel
安装 smartmontool 以显示 tlp-stat 中 S.M.A.R.T. 数据。
-
$ sudo dnf install smartmontools
对于 Debian/Ubuntu 系统，使用 APT-GET 命令 或 APT 命令 安装 TLP。
-
$ sudo apt install tlp tlp-rdw
ThinkPad 需要一些附加软件包。
-
$ sudo apt-get install tp-smapi-dkms acpi-call-dkms
安装 smartmontool 以显示 tlp-stat 中 S.M.A.R.T. 数据。
-
$ sudo apt-get install smartmontools
当基于 Ubuntu 的系统的官方软件包过时时，请使用以下 PPA 存储库，该存储库提供最新版本。运行以下命令以使用 PPA 安装 TLP。
-
$ sudo apt-get install tlp tlp-rdw
对于基于 Arch Linux 的系统，使用 Pacman 命令 安装 TLP。
-
$ sudo pacman -S tlp tlp-rdw
ThinkPad 需要一些附加软件包。
-
$ pacman -S tp_smapi acpi_call
安装 smartmontool 以显示 tlp-stat 中 S.M.A.R.T. 数据。
-
$ sudo pacman -S smartmontools
对于基于 Arch Linux 的系统，在启动时启用 TLP 和 TLP-Sleep 服务。
-
$ sudo systemctl enable tlp.service
-
$ sudo systemctl enable tlp-sleep.service
对于基于 Arch Linux 的系统，你还应该屏蔽以下服务以避免冲突，并确保 TLP 的无线电设备切换选项的正确操作。
-
$ sudo systemctl mask systemd-rfkill.service
-
$ sudo systemctl mask systemd-rfkill.socket
对于 RHEL/CentOS 系统，使用 YUM 命令 安装 TLP。
-
$ sudo yum install tlp tlp-rdw
安装 smartmontool 以显示 tlp-stat 中 S.M.A.R.T. 数据。
-
$ sudo yum install smartmontools
对于 openSUSE Leap 系统，使用 Zypper 命令 安装 TLP。
-
$ sudo zypper install TLP
安装 smartmontool 以显示 tlp-stat 中 S.M.A.R.T. 数据。
-
$ sudo zypper install smartmontools
成功安装 TLP 后，使用以下命令启动服务。
-
$ systemctl start tlp.service
使用方法
显示电池信息
-
$ sudo tlp-stat -b
-
或
-
$ sudo tlp-stat --battery
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Battery Status
-
/sys/class/power_supply/BAT0/manufacturer = SMP
-
/sys/class/power_supply/BAT0/model_name = L14M4P23
-
/sys/class/power_supply/BAT0/cycle_count = (not supported)
-
/sys/class/power_supply/BAT0/energy_full_design = 60000 [mWh]
-
/sys/class/power_supply/BAT0/energy_full = 48850 [mWh]
-
/sys/class/power_supply/BAT0/energy_now = 48850 [mWh]
-
/sys/class/power_supply/BAT0/power_now = 0 [mW]
-
/sys/class/power_supply/BAT0/status = Full
-
-
Charge = 100.0 [%]
-
Capacity = 81.4 [%]
显示磁盘信息
-
$ sudo tlp-stat -d
-
或
-
$ sudo tlp-stat --disk
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Storage Devices
-
/dev/sda:
-
Model = WDC WD10SPCX-24HWST1
-
Firmware = 02.01A02
-
APM Level = 128
-
Status = active/idle
-
Scheduler = mq-deadline
-
-
Runtime PM: control = on, autosuspend_delay = (not available)
-
-
SMART info:
-
4 Start_Stop_Count = 18787
-
5 Reallocated_Sector_Ct = 0
-
9 Power_On_Hours = 606 [h]
-
12 Power_Cycle_Count = 1792
-
193 Load_Cycle_Count = 25775
-
194 Temperature_Celsius = 31 [°C]
-
-
-
+++ AHCI Link Power Management (ALPM)
-
/sys/class/scsi_host/host0/link_power_management_policy = med_power_with_dipm
-
/sys/class/scsi_host/host1/link_power_management_policy = med_power_with_dipm
-
/sys/class/scsi_host/host2/link_power_management_policy = med_power_with_dipm
-
/sys/class/scsi_host/host3/link_power_management_policy = med_power_with_dipm
-
-
+++ AHCI Host Controller Runtime Power Management
-
/sys/bus/pci/devices/0000:00:17.0/ata1/power/control = on
-
/sys/bus/pci/devices/0000:00:17.0/ata2/power/control = on
-
/sys/bus/pci/devices/0000:00:17.0/ata3/power/control = on
-
/sys/bus/pci/devices/0000:00:17.0/ata4/power/control = on
显示 PCI 设备信息
-
$ sudo tlp-stat -e
-
或
-
$ sudo tlp-stat --pcie
-
$ sudo tlp-stat -e
-
or
-
$ sudo tlp-stat --pcie
-
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Runtime Power Management
-
Device blacklist = (not configured)
-
Driver blacklist = amdgpu nouveau nvidia radeon pcieport
-
-
/sys/bus/pci/devices/0000:00:00.0/power/control = auto (0x060000, Host bridge, skl_uncore)
-
/sys/bus/pci/devices/0000:00:01.0/power/control = auto (0x060400, PCI bridge, pcieport)
-
/sys/bus/pci/devices/0000:00:02.0/power/control = auto (0x030000, VGA compatible controller, i915)
-
/sys/bus/pci/devices/0000:00:14.0/power/control = auto (0x0c0330, USB controller, xhci_hcd)
-
-
......
显示图形卡信息
-
$ sudo tlp-stat -g
-
或
-
$ sudo tlp-stat --graphics
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Intel Graphics
-
/sys/module/i915/parameters/enable_dc = -1 (use per-chip default)
-
/sys/module/i915/parameters/enable_fbc = 1 (enabled)
-
/sys/module/i915/parameters/enable_psr = 0 (disabled)
-
/sys/module/i915/parameters/modeset = -1 (use per-chip default)
显示处理器信息
-
$ sudo tlp-stat -p
-
或
-
$ sudo tlp-stat --processor
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Processor
-
CPU model = Intel(R) Core(TM) i7-6700HQ CPU @ 2.60GHz
-
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_driver = intel_pstate
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_governor = powersave
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_available_governors = performance powersave
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_min_freq = 800000 [kHz]
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_max_freq = 3500000 [kHz]
-
/sys/devices/system/cpu/cpu0/cpufreq/energy_performance_preference = balance_power
-
/sys/devices/system/cpu/cpu0/cpufreq/energy_performance_available_preferences = default performance balance_performance balance_power power
-
-
......
-
-
/sys/devices/system/cpu/intel_pstate/min_perf_pct = 22 [%]
-
/sys/devices/system/cpu/intel_pstate/max_perf_pct = 100 [%]
-
/sys/devices/system/cpu/intel_pstate/no_turbo = 0
-
/sys/devices/system/cpu/intel_pstate/turbo_pct = 33 [%]
-
/sys/devices/system/cpu/intel_pstate/num_pstates = 28
-
-
x86_energy_perf_policy: program not installed.
-
-
/sys/module/workqueue/parameters/power_efficient = Y
-
/proc/sys/kernel/nmi_watchdog = 0
-
-
+++ Undervolting
-
PHC kernel not available.
显示系统数据信息
-
$ sudo tlp-stat -s
-
或
-
$ sudo tlp-stat --system
-
--- TLP 1.1 --------------------------------------------
-
-
+++ System Info
-
System = LENOVO Lenovo ideapad Y700-15ISK 80NV
-
BIOS = CDCN35WW
-
Release = "Manjaro Linux"
-
Kernel = 4.19.6-1-MANJARO #1 SMP PREEMPT Sat Dec 1 12:21:26 UTC 2018 x86_64
-
/proc/cmdline = BOOT_IMAGE=/boot/vmlinuz-4.19-x86_64 root=UUID=69d9dd18-36be-4631-9ebb-78f05fe3217f rw quiet resume=UUID=a2092b92-af29-4760-8e68-7a201922573b
-
Init system = systemd
-
Boot mode = BIOS (CSM, Legacy)
-
-
+++ TLP Status
-
State = enabled
-
Last run = 11:04:00 IST, 596 sec(s) ago
-
Mode = battery
-
Power source = battery
显示温度和风扇速度信息
-
$ sudo tlp-stat -t
-
或
-
$ sudo tlp-stat --temp
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Temperatures
-
CPU temp = 36 [°C]
-
Fan speed = (not available)
显示 USB 设备数据信息
-
$ sudo tlp-stat -u
-
或
-
$ sudo tlp-stat --usb
-
--- TLP 1.1 --------------------------------------------
-
-
+++ USB
-
Autosuspend = disabled
-
Device whitelist = (not configured)
-
Device blacklist = (not configured)
-
Bluetooth blacklist = disabled
-
Phone blacklist = disabled
-
WWAN blacklist = enabled
-
-
Bus 002 Device 001 ID 1d6b:0003 control = auto, autosuspend_delay_ms = 0 -- Linux Foundation 3.0 root hub (hub)
-
Bus 001 Device 003 ID 174f:14e8 control = auto, autosuspend_delay_ms = 2000 -- Syntek (uvcvideo)
-
-
......
显示警告信息
-
$ sudo tlp-stat -w
-
或
-
$ sudo tlp-stat --warn
-
--- TLP 1.1 --------------------------------------------
-
-
No warnings detected.
状态报告及配置和所有活动的设置
-
$ sudo tlp-stat
-
--- TLP 1.1 --------------------------------------------
-
-
+++ Configured Settings: /etc/default/tlp
-
TLP_ENABLE=1
-
TLP_DEFAULT_MODE=AC
-
TLP_PERSISTENT_DEFAULT=0
-
DISK_IDLE_SECS_ON_AC=0
-
DISK_IDLE_SECS_ON_BAT=2
-
MAX_LOST_WORK_SECS_ON_AC=15
-
MAX_LOST_WORK_SECS_ON_BAT=60
-
-
......
-
-
+++ System Info
-
System = LENOVO Lenovo ideapad Y700-15ISK 80NV
-
BIOS = CDCN35WW
-
Release = "Manjaro Linux"
-
Kernel = 4.19.6-1-MANJARO #1 SMP PREEMPT Sat Dec 1 12:21:26 UTC 2018 x86_64
-
/proc/cmdline = BOOT_IMAGE=/boot/vmlinuz-4.19-x86_64 root=UUID=69d9dd18-36be-4631-9ebb-78f05fe3217f rw quiet resume=UUID=a2092b92-af29-4760-8e68-7a201922573b
-
Init system = systemd
-
Boot mode = BIOS (CSM, Legacy)
-
-
+++ TLP Status
-
State = enabled
-
Last run = 11:04:00 IST, 684 sec(s) ago
-
Mode = battery
-
Power source = battery
-
-
+++ Processor
-
CPU model = Intel(R) Core(TM) i7-6700HQ CPU @ 2.60GHz
-
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_driver = intel_pstate
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_governor = powersave
-
/sys/devices/system/cpu/cpu0/cpufreq/scaling_available_governors = performance powersave
-
-
......
-
-
/sys/devices/system/cpu/intel_pstate/min_perf_pct = 22 [%]
-
/sys/devices/system/cpu/intel_pstate/max_perf_pct = 100 [%]
-
/sys/devices/system/cpu/intel_pstate/no_turbo = 0
-
/sys/devices/system/cpu/intel_pstate/turbo_pct = 33 [%]
-
/sys/devices/system/cpu/intel_pstate/num_pstates = 28
-
-
x86_energy_perf_policy: program not installed.
-
-
/sys/module/workqueue/parameters/power_efficient = Y
-
/proc/sys/kernel/nmi_watchdog = 0
-
-
+++ Undervolting
-
PHC kernel not available.
-
-
+++ Temperatures
-
CPU temp = 42 [°C]
-
Fan speed = (not available)
-
-
+++ File System
-
/proc/sys/vm/laptop_mode = 2
-
/proc/sys/vm/dirty_writeback_centisecs = 6000
-
/proc/sys/vm/dirty_expire_centisecs = 6000
-
/proc/sys/vm/dirty_ratio = 20
-
/proc/sys/vm/dirty_background_ratio = 10
-
-
+++ Storage Devices
-
/dev/sda:
-
Model = WDC WD10SPCX-24HWST1
-
Firmware = 02.01A02
-
APM Level = 128
-
Status = active/idle
-
Scheduler = mq-deadline
-
-
Runtime PM: control = on, autosuspend_delay = (not available)
-
-
SMART info:
-
4 Start_Stop_Count = 18787
-
5 Reallocated_Sector_Ct = 0
-
9 Power_On_Hours = 606 [h]
-
12 Power_Cycle_Count = 1792
-
193 Load_Cycle_Count = 25777
-
194 Temperature_Celsius = 31 [°C]
-
-
-
+++ AHCI Link Power Management (ALPM)
-
/sys/class/scsi_host/host0/link_power_management_policy = med_power_with_dipm
-
/sys/class/scsi_host/host1/link_power_management_policy = med_power_with_dipm
-
/sys/class/scsi_host/host2/link_power_management_policy = med_power_with_dipm
-
/sys/class/scsi_host/host3/link_power_management_policy = med_power_with_dipm
-
-
+++ AHCI Host Controller Runtime Power Management
-
/sys/bus/pci/devices/0000:00:17.0/ata1/power/control = on
-
/sys/bus/pci/devices/0000:00:17.0/ata2/power/control = on
-
/sys/bus/pci/devices/0000:00:17.0/ata3/power/control = on
-
/sys/bus/pci/devices/0000:00:17.0/ata4/power/control = on
-
-
+++ PCIe Active State Power Management
-
/sys/module/pcie_aspm/parameters/policy = powersave
-
-
+++ Intel Graphics
-
/sys/module/i915/parameters/enable_dc = -1 (use per-chip default)
-
/sys/module/i915/parameters/enable_fbc = 1 (enabled)
-
/sys/module/i915/parameters/enable_psr = 0 (disabled)
-
/sys/module/i915/parameters/modeset = -1 (use per-chip default)
-
-
+++ Wireless
-
bluetooth = on
-
wifi = on
-
wwan = none (no device)
-
-
hci0(btusb) : bluetooth, not connected
-
wlp8s0(iwlwifi) : wifi, connected, power management = on
-
-
+++ Audio
-
/sys/module/snd_hda_intel/parameters/power_save = 1
-
/sys/module/snd_hda_intel/parameters/power_save_controller = Y
-
-
+++ Runtime Power Management
-
Device blacklist = (not configured)
-
Driver blacklist = amdgpu nouveau nvidia radeon pcieport
-
-
/sys/bus/pci/devices/0000:00:00.0/power/control = auto (0x060000, Host bridge, skl_uncore)
-
/sys/bus/pci/devices/0000:00:01.0/power/control = auto (0x060400, PCI bridge, pcieport)
-
/sys/bus/pci/devices/0000:00:02.0/power/control = auto (0x030000, VGA compatible controller, i915)
-
-
......
-
-
+++ USB
-
Autosuspend = disabled
-
Device whitelist = (not configured)
-
Device blacklist = (not configured)
-
Bluetooth blacklist = disabled
-
Phone blacklist = disabled
-
WWAN blacklist = enabled
-
-
Bus 002 Device 001 ID 1d6b:0003 control = auto, autosuspend_delay_ms = 0 -- Linux Foundation 3.0 root hub (hub)
-
Bus 001 Device 003 ID 174f:14e8 control = auto, autosuspend_delay_ms = 2000 -- Syntek (uvcvideo)
-
Bus 001 Device 002 ID 17ef:6053 control = on, autosuspend_delay_ms = 2000 -- Lenovo (usbhid)
-
Bus 001 Device 004 ID 8087:0a2b control = auto, autosuspend_delay_ms = 2000 -- Intel Corp. (btusb)
-
Bus 001 Device 001 ID 1d6b:0002 control = auto, autosuspend_delay_ms = 0 -- Linux Foundation 2.0 root hub (hub)
-
-
+++ Battery Status
-
/sys/class/power_supply/BAT0/manufacturer = SMP
-
/sys/class/power_supply/BAT0/model_name = L14M4P23
-
/sys/class/power_supply/BAT0/cycle_count = (not supported)
-
/sys/class/power_supply/BAT0/energy_full_design = 60000 [mWh]
-
/sys/class/power_supply/BAT0/energy_full = 51690 [mWh]
-
/sys/class/power_supply/BAT0/energy_now = 50140 [mWh]
-
/sys/class/power_supply/BAT0/power_now = 12185 [mW]
-
/sys/class/power_supply/BAT0/status = Discharging
-
-
Charge = 97.0 [%]
-
Capacity = 86.2 [%]
via: https://www.2daygeek.com/tlp-increase-optimize-linux-laptop-battery-life/
作者：Magesh Maruthamuthu 选题：lujun9972 译者：wxy 校对：wxy
登录查看更多
相关内容
Arxiv
7+阅读 · 2019年6月14日
Arxiv
6+阅读 · 2018年1月21日
相关VIP内容
相关资讯
相关论文
Arxiv
7+阅读 · 2019年6月14日
Arxiv
6+阅读 · 2018年1月21日
微信扫码咨询专知VIP会员
