如何在线应对SQL语句执行计划？解读RDS MySQL 8.0之SQL Outline功能
作者：阿里云数据库产品事业部
高级技术专家 冷香
背景
在生产环境，MySQL 数据库实例运行过程中，一些 SQL 语句会发生执行计划的变化，导致增加了数据库稳定性的风险。
这里边有几个因素和场景，比如：随着表数据量的变化，以及统计信息的自动收集，CBO optimizer 计算得到了一个cost 更低的 plan， 又或者 表结构发生了变化，增加和删减了某些索引，或者在实例升级迁移等过程中，MySQL 自身优化器行为和算法发生了变化等。
为了能够在线应对和干预业务SQL语句的执行计划，AliSQL设计了一套利用 MySQL optimizer/index hint 来稳定执行计划的方法，称为 Statement outline，并提供了一组管理接口方便使用（DBMS_OUTLN package）， 并在阿里云RDS MySQL 8.0 产品上公开使用。
Outline设计
AliSQL 8.0 outline 支持 MySQL 8.0 官方支持的所有 hint 类型，主要分为两大类：
Optimizer Hint
根据作用域（query block）和 hint 对象，又分为：Global level hint，Table/Index level hint,
Join order hint等等。
详细信息参考：
https://dev.mysql.com/doc/refman/8.0/en/optimizer-hints.html
Index Hint
主要根据 index hint 的类型 （USE, FORCE, IGNORE）和 scope （FOR JOIN, FOR ORDER BY,
FOR GROUP BY）进行分类。
详细语法参考：
https://dev.mysql.com/doc/refman/8.0/en/index-hints.html
为了表示和抽象这些 Hint，并能够持久化 outline，AliSQL 8.0 增加了一个系统表 mysql.outline，其结构如下：
MYSQL.OUTLINE
CREATE TABLE `mysql`.`outline` (
`Id` bigint(20) NOT NULL AUTO_INCREMENT,
`Schema_name` varchar(64) COLLATE utf8_bin DEFAULT NULL,
`Digest` varchar(64) COLLATE utf8_bin NOT NULL,
`Digest_text` longtext COLLATE utf8_bin,
`Type` enum('IGNORE INDEX','USE INDEX','FORCE INDEX','OPTIMIZER') CHARACTER SET utf8 COLLATE utf8_general_ci NOT NULL,
`Scope` enum('','FOR JOIN','FOR ORDER BY','FOR GROUP BY') CHARACTER SET utf8 COLLATE utf8_general_ci DEFAULT '',
`State` enum('N','Y') CHARACTER SET utf8 COLLATE utf8_general_ci NOT NULL DEFAULT 'Y',
`Position` bigint(20) NOT NULL,
`Hint` text COLLATE utf8_bin NOT NULL,
PRIMARY KEY (`Id`)
) /*!50100 TABLESPACE `mysql` */ ENGINE=InnoDB
DEFAULT CHARSET=utf8 COLLATE=utf8_bin STATS_PERSISTENT=0 COMMENT='Statement outline'
Columns 说明
Digest/Digest_text
Outline 根据语句的特征进行匹配，这个特征就是 Digest text，根据这个 Digest Text 进行 hash 计算得到一个 64 字节的 hash 字符串。例如：
Statement query: select * from t1 where id = 1
根据计算得到的Digest 和 Digest text 分别是：
Digest ：36bebc61fce7e32b93926aec3fdd790dad5d895107e2d8d3848d1c60b74bcde6
Digest_text: SELECT * FROM `t1` WHERE `id` = ?
当语句 parse 完之后， 会根据 [schema + digest] 作为 hash key，进行查询匹配的 Outline。
Type
Optimizer hint 的 type 统一为 OPTIMIZER.
Index hint 分为三类， 分别是：
USE INDEX
FORCE INDEX
IGNORE INDEX
Scope
scope 只针对 Index hint 而言，分为四类：
FOR GROUP BY
FOR ORDER BY
FOR JOIN
ALL
Position
Optimizer hint
position 表示 Query Block， 因为所有的 optimizer hint 必须作用到 Query Block上，
这里判断比较简单， 因为 Optimizer hint 只支持 这几类关键字：
SELECT /*+ ... */ ...
INSERT /*+ ... */ ...
REPLACE /*+ ... */ ...
UPDATE /*+ ... */ ...
DELETE /*+ ... */ ...所以，position 从 1 开始，hint 作用在语句的第几个关键字锚点上，就是第几个。
Index hint
position 表示 table position， 也是从1开始，hint作用在第几个 table 锚点上，就是第几个。
Hint
在 Index hint 中， 这里表示的是 索引名字的列表， 比如 “ind_1, ind_2”
在 Optimizer hint 中， 这里表示的就是完整的 hint 字符串，比如：
“/+ MAX_EXECUTION_TIME(1000) /”
用户接口
为了更方便的管理 Statement outline，AliSQL 设计了一个 DBMS_OUTLN package 来进行管理，并提供了 6 个native procedure 接口：
DBMS_OUTLN.add_index_outline(); 增加 index hint
DBMS_OUTLN.add_optimizer_outline(); 增加 optimizer hint
DBMS_OUTLN.preview_outline(); 预览某一个 SQL 语句命中 outline 的情况
DBMS_OUTLN.show_outline(); 展示内存中可用的所有 outline 及命中情况
DBMS_OUTLN.del_outline(); 删除内存和持久化表中的 outline
DBMS_OUTLN.flush_outline(); 刷新所有的 outline，从 mysql.outline 表中重新 load
为了方便的介绍 DBMS_OUTLN 的使用，这里使用一些测试表：
CREATE TABLE `t1` (
`id` int(11) NOT NULL AUTO_INCREMENT,
`col1` int(11) DEFAULT NULL,
`col2` varchar(100) DEFAULT NULL,
PRIMARY KEY (`id`),
KEY `ind_1` (`col1`),
KEY `ind_2` (`col2`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;
CREATE TABLE `t2` (
`id` int(11) NOT NULL AUTO_INCREMENT,
`col1` int(11) DEFAULT NULL,
`col2` varchar(100) DEFAULT NULL,
PRIMARY KEY (`id`),
KEY `ind_1` (`col1`),
KEY `ind_2` (`col2`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8;
1. Add index outline
语法和参数
CALL DBMS_OUTLN.add_index_outline(schema=>, digest=>, position=>, type=>,
scope=>, hint=>, query=>);
说明：
digest 和 query 可以选择其一， 如果填写了原始query语句，这个 proc 会计算 digest 和 digest text。测试 case 1
测试语句
select * from t1 where t1.col1 =1 and t1.col2 ='xpchild';使用 ind_1 的索引
call dbms_outln.add_index_outline('outline_db', '', 1, 'USE INDEX', 'ind_1', '',
"select * from t1 where t1.col1 =1 and t1.col2 ='xpchild'");
查看 outline：
mysql> call dbms_outln.show_outline();
+------+------------+------------------------------------------------------------------+-----------+-------+------+-------+------+----------+------------------------------------------------------------------+
| ID | SCHEMA | DIGEST | TYPE | SCOPE | POS | HINT | HIT | OVERFLOW | DIGEST_TEXT |
+------+------------+------------------------------------------------------------------+-----------+-------+------+-------+------+----------+------------------------------------------------------------------+
| 30 | outline_db | b4369611be7ab2d27c85897632576a04bc08f50b928a1d735b62d0a140628c4c | USE INDEX | | 1 | ind_1 | 0 | 0 | SELECT * FROM `t1` WHERE `t1` . `col1` = ? AND `t1` . `col2` = ? |
+------+------------+------------------------------------------------------------------+-----------+-------+------+-------+------+----------+------------------------------------------------------------------+
1 row in set (0.00 sec)验证 Outline
验证 Outline 是否其效果，可以有两种方法：
dbms_outln.preview_outline() 进行预览：
直接使用 explain 进行查看：
mysql> call dbms_outln.preview_outline('outline_db', "select * from t1 where t1.col1 =1 and t1.col2 ='xpchild'");
+------------+------------------------------------------------------------------+------------+------------+-------+---------------------+
| SCHEMA | DIGEST | BLOCK_TYPE | BLOCK_NAME | BLOCK | HINT |
+------------+------------------------------------------------------------------+------------+------------+-------+---------------------+
| outline_db | b4369611be7ab2d27c85897632576a04bc08f50b928a1d735b62d0a140628c4c | TABLE | t1 | 1 | USE INDEX (`ind_1`) |
+------------+------------------------------------------------------------------+------------+------------+-------+---------------------+
1 row in set (0.01 sec)
mysql> explain select * from t1 where t1.col1 =1 and t1.col2 ='xpchild';
+----+-------------+-------+------------+------+---------------+-------+---------+-------+------+----------+-------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+-------------+-------+------------+------+---------------+-------+---------+-------+------+----------+-------------+
| 1 | SIMPLE | t1 | NULL | ref | ind_1 | ind_1 | 5 | const | 1 | 100.00 | Using where |
+----+-------------+-------+------------+------+---------------+-------+---------+-------+------+----------+-------------+
1 row in set, 1 warning (0.00 sec)
mysql> show warnings;
+-------+------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Level | Code | Message |
+-------+------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Note | 1003 | /* select#1 */ select `outline_db`.`t1`.`id` AS `id`,`outline_db`.`t1`.`col1` AS `col1`,`outline_db`.`t1`.`col2` AS `col2` from `outline_db`.`t1` USE INDEX (`ind_1`) where ((`outline_db`.`t1`.`col1` = 1) and (`outline_db`.`t1`.`col2` = 'xpchild')) |
+-------+------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)测试 case 2
测试语句：
select * from t1, t2 where t1.col1 = t2.col1 and t2.col2 ='xpchild'测试使用 t2 表的 ind_2 索引：
call dbms_outln.add_index_outline('outline_db', '', 2, 'USE INDEX', 'ind_2', '',
"select * from t1, t2 where t1.col1 = t2.col1 and t2.col2 ='xpchild'");
验证 Outline
mysql> explain select * from t1, t2 where t1.col1 = t2.col1 and t2.col2 ='xpchild';
+----+-------------+-------+------------+------+---------------+-------+---------+-------+------+----------+-------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+-------------+-------+------------+------+---------------+-------+---------+-------+------+----------+-------------+
| 1 | SIMPLE | t1 | NULL | ALL | ind_1 | NULL | NULL | NULL | 1 | 100.00 | NULL |
| 1 | SIMPLE | t2 | NULL | ref | ind_2 | ind_2 | 303 | const | 1 | 100.00 | Using where |
+----+-------------+-------+------------+------+---------------+-------+---------+-------+------+----------+-------------+
2 rows in set, 1 warning (0.01 sec)
mysql> show warnings;
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Level | Code | Message |
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Note | 1003 | /* select#1 */ select `outline_db`.`t1`.`id` AS `id`,`outline_db`.`t1`.`col1` AS `col1`,`outline_db`.`t1`.`col2` AS `col2`,`outline_db`.`t2`.`id` AS `id`,`outline_db`.`t2`.`col1` AS `col1`,`outline_db`.`t2`.`col2` AS `col2` from `outline_db`.`t1` join `outline_db`.`t2` USE INDEX (`ind_2`) where ((`outline_db`.`t2`.`col1` = `outline_db`.`t1`.`col1`) and (`outline_db`.`t2`.`col2` = 'xpchild')) |
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
2. Add optimizer outline
语法和参数
CALL DBMS_OUTLN.add_optimizer_outline(schema=>, digest=>, query_block=>
hint=>, query=>);
说明：digest 和 query 同样可以填其一，或者都填入。proc 会自动计算digest 和 digest text。测试 case 1
增加全局 MAX_EXECUTION_TIME / SET VAR optimizer hint;
CALL DBMS_OUTLN.add_optimizer_outline("outline_db", '', 1, '/*+ MAX_EXECUTION_TIME(1000) */',
"select * from t1 where id = 1");
CALL DBMS_OUTLN.add_optimizer_outline("outline_db", '', 1, '/*+ SET_VAR(foreign_key_checks=OFF) */',
"select * from t1 where id = 1");验证 Outline
mysql> explain select * from t1 where id = 1;
+----+-------------+-------+------------+------+---------------+------+---------+------+------+----------+--------------------------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+-------------+-------+------------+------+---------------+------+---------+------+------+----------+--------------------------------+
| 1 | SIMPLE | NULL | NULL | NULL | NULL | NULL | NULL | NULL | NULL | NULL | no matching row in const table |
+----+-------------+-------+------------+------+---------------+------+---------+------+------+----------+--------------------------------+
1 row in set, 1 warning (0.01 sec)
mysql> show warnings;
+-------+------+-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Level | Code | Message |
+-------+------+-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Note | 1003 | /* select#1 */ select /*+ MAX_EXECUTION_TIME(1000) SET_VAR(foreign_key_checks='OFF') */ NULL AS `id`,NULL AS `col1`,NULL AS `col2` from `outline_db`.`t1` where multiple equal(1, NULL) |
+-------+------+-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
测试 case 2
测试多表关联查询：Nested-Loop join processing
CALL DBMS_OUTLN.add_optimizer_outline('outline_db', '', 1, '/*+ BNL(t1,t2) */',
"select t1.id, t2.id from t1,t2");验证Outline：
mysql> explain select t1.id, t2.id from t1,t2;
+----+-------------+-------+------------+-------+---------------+-------+---------+------+------+----------+----------------------------------------------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+-------------+-------+------------+-------+---------------+-------+---------+------+------+----------+----------------------------------------------------+
| 1 | SIMPLE | t1 | NULL | index | NULL | ind_1 | 5 | NULL | 1 | 100.00 | Using index |
| 1 | SIMPLE | t2 | NULL | index | NULL | ind_1 | 5 | NULL | 1 | 100.00 | Using index; Using join buffer (Block Nested Loop) |
+----+-------------+-------+------------+-------+---------------+-------+---------+------+------+----------+----------------------------------------------------+
2 rows in set, 1 warning (0.01 sec)
mysql> show warnings;
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Level | Code | Message |
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Note | 1003 | /* select#1 */ select /*+ BNL(`t1`@`select#1`) BNL(`t2`@`select#1`) */ `outline_db`.`t1`.`id` AS `id`,`outline_db`.`t2`.`id` AS `id` from `outline_db`.`t1` join `outline_db`.`t2` |
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
测试 case 3
测试 subquery 中带有 query block name 的情况
CALL DBMS_OUTLN.add_optimizer_outline('outline_db', '', 2, ' /*+ QB_NAME(subq1) */',
"SELECT * FROM t1 WHERE t1.col1 IN (SELECT col1 FROM t2)");
CALL DBMS_OUTLN.add_optimizer_outline('outline_db', '', 1, '/*+ SEMIJOIN(@subq1 MATERIALIZATION, DUPSWEEDOUT) */ ',
"SELECT * FROM t1 WHERE t1.col1 IN (SELECT col1 FROM t2)");
验证 Outline：
mysql> explain SELECT * FROM t1 WHERE t1.col1 IN (SELECT col1 FROM t2);
+----+--------------+-------------+------------+--------+---------------+------------+---------+--------------------+------+----------+-------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+--------------+-------------+------------+--------+---------------+------------+---------+--------------------+------+----------+-------------+
| 1 | SIMPLE | t1 | NULL | ALL | ind_1 | NULL | NULL | NULL | 1 | 100.00 | Using where |
| 1 | SIMPLE | <subquery2> | NULL | eq_ref | <auto_key> | <auto_key> | 5 | outline_db.t1.col1 | 1 | 100.00 | NULL |
| 2 | MATERIALIZED | t2 | NULL | index | ind_1 | ind_1 | 5 | NULL | 1 | 100.00 | Using index |
+----+--------------+-------------+------------+--------+---------------+------------+---------+--------------------+------+----------+-------------+
3 rows in set, 1 warning (0.00 sec)
mysql> show warnings;
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Level | Code | Message |
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Note | 1003 | /* select#1 */ select /*+ SEMIJOIN(@`subq1` MATERIALIZATION, DUPSWEEDOUT) */ `outline_db`.`t1`.`id` AS `id`,`outline_db`.`t1`.`col1` AS `col1`,`outline_db`.`t1`.`col2` AS `col2` from `outline_db`.`t1` semi join (`outline_db`.`t2`) where (`<subquery2>`.`col1` = `outline_db`.`t1`.`col1`) |
+-------+------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
3. Preview outline
dbms_outln.preview_outline() 具体 SQL 语句，查看匹配 Outline 的情况，用于手动验证。
其语法和参数：
CALL DBMS_OUTLN.preview_outline(schema=>, query=>);例如：
mysql> call dbms_outln.preview_outline('outline_db', "select * from t1 where t1.col1 =1 and t1.col2 ='xpchild'");
+------------+------------------------------------------------------------------+------------+------------+-------+---------------------+
| SCHEMA | DIGEST | BLOCK_TYPE | BLOCK_NAME | BLOCK | HINT |
+------------+------------------------------------------------------------------+------------+------------+-------+---------------------+
| outline_db | b4369611be7ab2d27c85897632576a04bc08f50b928a1d735b62d0a140628c4c | TABLE | t1 | 1 | USE INDEX (`ind_1`) |
+------------+------------------------------------------------------------------+------------+------------+-------+---------------------+
1 row in set (0.00 sec)
4. Show outline
dbms_outln.show_outline 展示 outline 在内存 cache 中 命中的情况，里边有两个字段:
- Hit：outline 命中的次数
- Overflow：outline hint 没有找到 query block 或者 相应的 table 的次数
例如：
mysql> call dbms_outln.show_outline();
+------+------------+------------------------------------------------------------------+-----------+-------+------+-------------------------------------------------------+------+----------+-------------------------------------------------------------------------------------+
| ID | SCHEMA | DIGEST | TYPE | SCOPE | POS | HINT | HIT | OVERFLOW | DIGEST_TEXT |
+------+------------+------------------------------------------------------------------+-----------+-------+------+-------------------------------------------------------+------+----------+-------------------------------------------------------------------------------------+
| 33 | outline_db | 36bebc61fce7e32b93926aec3fdd790dad5d895107e2d8d3848d1c60b74bcde6 | OPTIMIZER | | 1 | /*+ SET_VAR(foreign_key_checks=OFF) */ | 1 | 0 | SELECT * FROM `t1` WHERE `id` = ? |
| 32 | outline_db | 36bebc61fce7e32b93926aec3fdd790dad5d895107e2d8d3848d1c60b74bcde6 | OPTIMIZER | | 1 | /*+ MAX_EXECUTION_TIME(1000) */ | 2 | 0 | SELECT * FROM `t1` WHERE `id` = ? |
| 34 | outline_db | d4dcef634a4a664518e5fb8a21c6ce9b79fccb44b773e86431eb67840975b649 | OPTIMIZER | | 1 | /*+ BNL(t1,t2) */ | 1 | 0 | SELECT `t1` . `id` , `t2` . `id` FROM `t1` , `t2` |
| 35 | outline_db | 5a726a609b6fbfb76bb8f9d2a24af913a2b9d07f015f2ee1f6f2d12dfad72e6f | OPTIMIZER | | 2 | /*+ QB_NAME(subq1) */ | 2 | 0 | SELECT * FROM `t1` WHERE `t1` . `col1` IN ( SELECT `col1` FROM `t2` ) |
| 36 | outline_db | 5a726a609b6fbfb76bb8f9d2a24af913a2b9d07f015f2ee1f6f2d12dfad72e6f | OPTIMIZER | | 1 | /*+ SEMIJOIN(@subq1 MATERIALIZATION, DUPSWEEDOUT) */ | 2 | 0 | SELECT * FROM `t1` WHERE `t1` . `col1` IN ( SELECT `col1` FROM `t2` ) |
| 30 | outline_db | b4369611be7ab2d27c85897632576a04bc08f50b928a1d735b62d0a140628c4c | USE INDEX | | 1 | ind_1 | 3 | 0 | SELECT * FROM `t1` WHERE `t1` . `col1` = ? AND `t1` . `col2` = ? |
| 31 | outline_db | 33c71541754093f78a1f2108795cfb45f8b15ec5d6bff76884f4461fb7f33419 | USE INDEX | | 2 | ind_2 | 1 | 0 | SELECT * FROM `t1` , `t2` WHERE `t1` . `col1` = `t2` . `col1` AND `t2` . `col2` = ? |
+------+------------+------------------------------------------------------------------+-----------+-------+------+-------------------------------------------------------+------+----------+-------------------------------------------------------------------------------------+
7 rows in set (0.00 sec)
5. Delete outline
dbms_outln.del_outline() 可以删除内存和表中的某一条 outline。
语法和参数如下：
CALL DBMS_OUTLN.del_outline(outline_id=>);例如：
mysql> call dbms_outln.del_outline(1000);
Query OK, 0 rows affected, 2 warnings (0.00 sec)
mysql> show warnings;
+---------+------+----------------------------------------------+
| Level | Code | Message |
+---------+------+----------------------------------------------+
| Warning | 7521 | Statement outline 1000 is not found in table |
| Warning | 7521 | Statement outline 1000 is not found in cache |
+---------+------+----------------------------------------------+
2 rows in set (0.00 sec)
6. Flush outline
dbms_outln.flush_outline() 支持清理 cache 中 outline，并从 mysql.outline 表中重新 load。
如果用户直接修改表来加载 outline，需要调用 flush 到 cache 中。
例如：
mysql> call dbms_outln.flush_outline();
Query OK, 0 rows affected (0.01 sec)
